Automatic Glass / PET Bottle Carbonated Soft Drinking Water Filling Machine Water Bottling Filling Machine
3-in-1 filling monoblock, combined with rinsing, filling and capping. water bottling filling machine is innovated and designed in the requirement of still pure water and mineral water, on the bases of introducing, digesting and absorbing advanced technology from Germany and Italy.
Product Application
1.The mineral water production line use direct connection technology between air conveyor and in-feeding star-wheel to substitute in-feeding screw and conveyor to ease the process of bottle-size-changing.
2. Neck-hanging technology is applied in bottle transportation of the automatic water filling machine. Instead of traditional star-wheel, we use neck-hanging gripper to make bottle-size-changing easily , without equipment height adjustment ,only arch board and star-wheel such little nylon parts need to be changed.
3. Specially-designed rinsing grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution in this automatic water filling machine.
4. Rapid gravity filling valve with high flow makes filling faster with accurate liquid level and without any liquid loss.
5. Splint of star-wheel using twist descending way to simplify the process of bottle-size-changing.
Product parameters
| Mode | CGF18-18-6 |
| Suitable bottle shape | circular or square |
| Bottle diameter(mm) | 50-95 |
| Bottle height | 150-310 mm |
| Washing medium | Aseptic Water |
| Total power | 3 Kw |
| Weight | 2200 Kg |
| Overall dimensions | 2050*1550*2200 mm |
Pictures
