mineral water filling machine plant automatic 500ml big liquid packing water filling machine
Plastic Bottle Minerial / Pure Water Filling Machine
Bottle Material: PET Bottle
Cap: PE
Bottle Volume: 100-2500ml
Production Speed: 1000-32000bph
Suitable Bottle:
Height 170-320
Diameter 20-100
Driving plate style feeding star-wheel, it is suitable for different bottle size and no needto change the height of machine
304 stainless steel washing pumps
All 304 stainless steel rinser heads, water spray style inject design, more save water consumption & more clean 304 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing
Filler
High precision filling nozzle, PLC variable signal control, ensure high filling precision Gravity filling, & filling smoothly & steadily All 304 stainless steel contact parts & liquid tank, fine polish, easy to clean No bottle no filling
capper station
Place & capping system,electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping All 304 stainless steel construction No bottle no capping and Automatic stop when lack of bottle
| Model | CGF14125 | CGF18186 | CGF24248 | CGF323210 | CGF404012 |
| Number of washing, filling and capping heads | 14-12-5 | 18-18-6 | 24-24-8 | 32-32-10 | 40-40-12 |
| Production capacity(600ml) (B/H) | 4000-5000 | 5000-6000 | 8000-12000 | 12000-15000 | 16000-20000 |
| suitable bottle specification(mm) | φ=50-110 H=170 volume=330-2250ml |
| Washing pressure(kg/cm2 ) | 2~3 |
| Motor power(kw) | Main motor 2.2kw | Main motor 3kw | Main motor 3.8kw | Main motor 5.5kw | Main motor 7.5kw |
| Overall dimensions (mm) | 2400×1650 ×2500 | 2400×1830 ×2400 | 3100×2200 ×2400 | 3800×2800 ×2900 | 4600×2800 ×2900 |
| Weight (kg) | 2500 | 3500 | 4000 | 6500 | 8500 |
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 20-30 days,if complete production line it is 45-60 days.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance
Before shippment.
Water treatment system.
1 Raw water tank + Raw water pump 2 Silica sand filter + Active carbon filter + Sodium ion exchanger + Precision filter + Security filter 3 Reverse Osmosis (one level) 4 UV sterilizer 5 Finished water tank + Pure water pump 1/Stainless steel high pressure film shell 2/All kinds of capacity indicator, pressure indicator, electricity magnetic valve, balance device and pipe valve system 3/Online type pressure auto self-protection device 4/Online type electricity indicator (with stable compensation) 5/System safe protecting and alarm system 6/System frame
Blow molding system.
Full automatic blow molding machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc
Automatic sleeve labeling machine
. 1/Heat shrink sleeve labeling machine 2/OPP Hot melt labeling machine 3/PVC label stick labeling machine It adopts double driving structure which is a new and advanced driving device for the thermal shrink sleeve machine, that is, four-wheel driving, self-centering and balanced pressure of four wheels. It can achieve the good effect of transmission of labels smoothly, stably and rapidly
PE film packaging machine.
1/PE film shrink wrapping machine 2/Half-tray shrink wrapping machine 3/Carton box packaging machine It adopts the photoelectric sensor to detect online, gather signals which are controlled by PLC, and adopts piston as executable element, to realize product conveying, combination, film wrapping, cutting, heat& shrink, cool and finally get the finished product.
Our certification
Best Drink Machine Advantages
